M3x6
8x14
5x5
M3x12
M3x12
M3x5
STEP
22
STEP
23
STEP
24
11
SHIFT POINT
SCREW
SHIFT POINT
SCREW
screw in all the way,
then unscrew 3 turns
screw in all the way,
then unscrew 3 turns
M4x4
8x10x1
R9
R6
STEP
25
Turn in all the way
then unscrew 3 turns
3x14
