903012 SERPENT 977 Viper 1/8 4WD KIT
ART N o. DES CR I PT I O N
MANUAL / DECALS
903604 Manual 977
903605 Decal sheet 977 black/white (2)
1887 Decal Serpent black/white 1/8 (2)
CHASSIS / RADIO PLATE
903506 Chassis alu 7075 T6 5mm
903543 Radioplate bracket
903606 Radioplate carbon
Optionals
903580 Weight bottom brass 38gr
903603 Radioplate bracket alu
RADIO INSTALLATION / BATTERY
1070 Grommet rubber soft (4)
1602 Tank-clips small (10)
1606 Antenna rod black (2)
1639 Collar alu 2.1+setscrew (4)
1650 Steel balls 5.8mm (4)
600500 Servo spacers (8)
804181 Throttle spring (2)
902115 Mounting-pin tank + rubber cap (2)
902116 Cap rubber for mounting pin tank (2)
902157 Roll-bar chrome
902170 Shaft throttle-brake lever
903231 Ball-joints frame 14+6+2
903519 Radiobox set
903530 Throttle lever set (2+1)
903543 Radioplate bracket
903549 Brake lever set (1+1+1)
903559 Battery mount set (1+2)
903560 Servo lever set (3+3)
903565 Grommet rubber big (4)
903566 Throttle/brake linkage (1+1)
Optionals
804214 Steering lever 23T alu
804215 Steering lever 24T alu
804216 Steering lever 25T alu
903588 Throttle lever alu
903603 Radioplate bracket alu
903576 Flex system front
903577 Transponder mount carbon
FRONT SECTION
1652 Steel balls 5.8mm long (4)
9212 Inner driveshaft adapter
401025 Pivotball-uni-4-5mm (20)
401058 Rod threaded arb L/R 16mm (4)
411048 Adjust nut for front suspension
411063 Pivot ball threaded upper arm (2)
411206 Balljoint 4.5 (4)
411207 Balljoint 4.5 short (2)
803198 Adj nut pivotball 8.5mm nylon (10)
804117 Pivot pin FR lw (2)
808214 Spacer-set caster (3)
808346 Pivot-balls 8.5mm (2)
902128 Track-rod set (2)
902134 Servo-saver shaft outer
902135 Servo-saver pre-tension nut
902139 Servo saver spring hard
902271 Springs quick-change short (4)
902280 Wheel-axles cvd set FR
902281 Driveshaft-set cvd FR
902282 Insert steel cvd (2)
903231 Ball-joints frame 14+6+2
903266 Wheel-axles cvd OS2 FR (2)
903267 Lever alu/spring/pin OS2 FR (2)
903290 Shim alu wheelaxle OS2 18x12x1mm (4)
903341 Antirollbar ball 3mm (2)
903343 Antirollbar spacer 3mm (2)
903500 Belt front 60S3M213 low friction
903504 Pulley-set side (2)
903505 Pulley-set front (2)
903508 Suspension bracket FR up inserts (4+4)
903509 Excenter-set nylon FR/RR
903512 Steeringblock lever alu (2)
903513 Middle shaft
903514 Bracket stiffner/radioplate mount L+R
903516 Pivot pin FR up (2)
903521 Shocktower FR carbon
903523 Steeringblock excenters 0 + 1.5 (4+4)
903524 Steeringblock (2)
903525 Stiffner plate FR carbon
903526 Support radioplate FR alu
903527 Suspension bracket FR lw (4+4)
903528 Suspension bracket FR up alu (2)
903542 Bearing bracket FR up
903544 Shock extension bracket FR alu (2)
903554 Bearing bushing 2-speed/mid axle (2+2)
903555 Bearing bushing antiroll bar FR+RR (2+2)
903556 Wishbone FR lw L+R
903557 Antiroll bar FR medium
903562 Bearingblock FR (2)
903563 Wishbone FR up (2)
903564 Middle shaft bearing block alu
903568 Servo saver set
903569 Servosaver shaft bushing (2)
903570 Servo saver shaft inner
903574 Oneway front axle
Optionals
804253 Pivotball 5.8mm alu coated long (4)
903378 Wheelaxle front OS2 alu (2)
903342 Antirollbar ball 2.5mm (2)
903344 Antirollbar spacer 2.5mm (2)
903396 Pivot-balls 8.5mm titanium (8)
903579 Rim cover FR carbon (2)
903581 Steeringblock lever carbon (2)
903582 Shock extension bracket FR carbon (2)
903584 Antiroll bar FR soft
903585 Antiroll bar FR hard
903589 Servosaver bottom alu (2)
903592 Pulley middle axle 25T alu
903593 Pulley middle axle 18T alu
903594 Pulley front axle 28T alu
903601 Driveshaft cvd FR alu (2)
903602 Bracket stiffner/radioplate mount L+R alu
MIDDLE SECTION
1494 Silicone tubing 2x5x50 white
1639 Collar alu 2.1+setscrew (4)
804181 Throttle spring (2)
804275 Exhaust mount spring (2)
901255 Belt tensioner shaft and nut
903231 Ball-joints frame 14+6+2
903299 Belt side 60S3M432 Low Friction
903504 Pulley-set side (2)
903507 Enginemount alu L+R
903535 Belt tensioner plate carbon
903549 Brake lever set (1+1+1)
903566 Throttle/brake linkage (1+1)
Optionals
903592 Pulley middle axle 25T alu
903593 Pulley middle axle 18T alu
903598 Mono enginemount alu
FUEL TANK AND PARTS
1493 Pressure nipple m3 (4)
1494 Silicone tubing 2x5x50 white
903573 Tank 125cc on-road 977
REAR SECTION
401025 Pivotball uni 4.5mm (20)
411206 Balljoint 4.5 (4)
803198 Adj nut pivotball 8.5mm nylon (10)
44
