Bag
6
M4x4
Neutral position
STEP
39
STEP
40
16
M3x12
Nylock
nut M3
3x7x0.5
Leading position when
mounted at LEFT hand side
Leading position when
mounted at RIGHT hand side
Trailing position when
mounted at LEFT hand side
Trailing position when
mounted at RIGHT hand side
OPTIONAL
OPTIONAL
