22
CENTRal aSSEmbly
STEp 37
Put thread lock in all the M3x6 screws
that x the sideguards to the chassis.
M3x6
M3x10
M3x10
M3x6
M3x6
Nylock Nut M3
Nylock Nut M3
Nylock Nut M3 M3x6 M3x10
