Serpent Cobra SRX8e - Shock Absorber Assembly

33
ShOCKS aSSEmbly
STEp 52 STEp 53
52.1
53.1
53.2
52.2
52.3
1
2
Use some silicone oil
during the assembly.
Use some silicone oil
during the assembly.
Insert the o-ring
inside the spring
collar.
Nylock Nut M2.5
2.5x6x0.5
2.5x6x0.5
Nylock Nut M2.5
bag 13 fR ShOCKS / bag 14 RR ShOCKS
Note the correct
orientation of the
shock spacers .
Note the correct
position of the
o-ring .
