34
STEp 54
STEp 55
54.1
54.2
55.3
SHOCKSLENGTH:Measure the
shock length fully extended.
Push the membrane
into the shock cap.
FRONT REAR
36.5
mm
44
mm
1- Fill up with sillicone oil
fully using the silicone
oil supplied in the kit.
For the correct cst value
please check the default
setupsheet.
2- Extend the shockrod fully
3- Move the shockrod
slowly up and down
to let ALL air bubbles
escape.
4- Close top only 3/4.
1-Bleed: push the
shockrod all the way
in slowly, to allow
excessive oil to escape.
2- Close completely the
shock cap.
Assemble the spring and spring-
cup (align correctly) to complete
the shock.
