Serpent Cobra SRX8e - Page 9

9
STEp 13 STEp 14
13.1
13.2
13x16x0.1
M3x22
13x16x0.1
2
1
1
M3X16
M3x22 M3x16
13x16x0.1
After 1 or 2 hours
of running the car,
re-check the gear-
mesh between the ring gear
and the pinion. All parts
should have run-in properly.
You may add or remove
13x16x0.1 shims as needed.
