Serpent F110 - Electronics and Final Assembly

Page
27
19C
A
Page
26
19B
A
NOT
INCLUDeD
NOT
INCLUDeD
NOT
INCLUDeD
M3X10
Tip: Use double sided tape to mount the ESC and RX
to the chassisplate.
Note: When using a
Shorty 2S Lipo install
ESC and RX as shown.
(Page 25 shows
Standard 2S Lipo set-
up).
Electronics configuration for using 2S STANDARD Lipo Batteries
Electronics configuration for using 2S SHORT Lipo Batteries
Electronics position with Shorty 2S Lipo
