Serpent Natrix 748 - Front Differential Assembly; Front Diff: Initial Lubrication and Fastening; Front Diff: Second Fastening and Lubrication; Front Diff: Filling with Silicone Oil

Page
4
STEP
1
STEP
2
STEP
3
STEP
4
FRONT DIFFERENTIAL ASSEMBLY
BAG
FRONT
DIFF
Oil level
M2.5x8
M2.5x8
5x15x0.2
Use some
Locktite on
this bolt
Use some
Locktite on
this bolt
Widethread
M2.5x12
Tighten all screws
step by step to close
the differential
5x15x0.2
3.1
4.1
3.2
4.2
Use some silicone oil
during assembly
Use some silicone oil
during assembly
Fill the diff case
with silicone oil till
the level showed
in the picture.
1
1
1
3
3
1
2
2
2
