Serpent Natrix 748 - Rear Differential Assembly; Rear Diff: Initial Lubrication and Fastening; Rear Diff: Second Fastening and Lubrication; Rear Diff: Filling with Silicone Oil

Page
5
STEP
5
STEP
6
STEP
7
STEP
8
BAG
REAR
DIFF
REAR DIFFERENTIAL ASSEMBLY
Oil level
M2.5x8
M2.5x8
5x15x0.2
Use some
Locktite on
this bolt
Use some
Locktite on
this bolt
Widethread
M2.5x12
Tighten all screws
step by step to close
the differential
5x15x0.2
7.1
8.1
7.2
8.2
Use some silicone oil
during assembly
Use some silicone oil
during assembly
Fill the diff case
with silicone oil till
the level showed
in the picture.
1
1
1
3
3
1
2
2
2
