SERV-WARE SECO-2201 - Basic Features & Parameters

www.servware.com
800•768•5953
Service, Installation & Care Manual
6
BASIC FEATURES AND PARAMETERS
Basic Features of the SECO Electric Convection Oven
Dimensions
38.11″ (968mm) × 41.46″ (1053mm) × 54.09″ (1374mm)
Net Weight
231.49 lbs (105kg)
Packing Dimensions (Wooden)
47. 24″ (1200mm) × 40.94″ (1040mm) × 38.58″ (980mm)
Gross Weight
Oven Capacity (LWH)
29.02″ (737mm) × 22.32″ (567mm) × 20″ (508mm)
Temperature Range
149°F (65°C) - 550.4°F (288°C)
Power Parameters
Model
Total
Power
(kW)
Voltage Phases
Amps Fan-50HZ Fan-60HZ
L1 L2 L3
High
Speed
Low
Speed
High
Speed
Low
Speed
SECO-2201 11 220 1 53 -- 53 1425 748 1725 850
Remark:
Each device needs a separate electrical connection. Only SECO-2081 and
SECO-2201 can be assembly into double stacked version.
