WOOD BOILER INSTRUCTIONS Page 61 Copyright © 2011 Seton Wood Boilers all rights reserved
IF YOU DO NOT HAVE AN OUT SIDE BUILDING FOR THE BOILER, THIS IS A PLAN
YOU COULD USE FOR THE BOILER AND WOOD STORAGE
SIDE VIEW
TOP VIEW
BOILER
CHIMNEY
16’ to 24’ ?
WOOD STORAGE
BOILER BUILDING
