SPECIFICATIONS
GENERAL
Supply Voltage : 14.4V DC (11-16V allowed)
Load Impedance : 4Ω per channel
Max Power Output : 55W x 4
Bass 100Hz : ≥ 10dB
Treble 10KHz : ≥ 10dB
Dimensions (approx.) : 188x183x58mm (d/w/h)
Mounting (approx.) : 350x235x105mm (d/w/h)
Weight (approx.) : 1.8Kg
FM TUNER
Frequency Range : 87.5 – 108 MHz (Europe/Asia)
87.5 – 107.9 MHz (USA)
IF : 10.7 MHz
Usable Sensitivity : ≤ 15dBuV
Stereo Separation : ≥ 26dB (1KHz)
Frequency Response : 100-20000Hz
AM TUNER
Frequency Range : 531 - 1602 KHz (Asia)
522 - 1620 KHz (Europe)
530 - 1710 KHz (USA)
IF : 450 KHz
Usable Sensitivity : ≤ 40dBuV
DVD PLAYER
Signal-to-noise Ratio : ≥ 85dB (1KHz)
Distortion : ≤ 0.5%
Note:
Specifications and design are subject to change without notice.
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.”
