SFA SANICUBIC 2 VX - SANICUBIC 2 VX Technical Data; Specifications and Flow Curves

SANICUBIC 2 VX
EN 12050-1
Sanicubic 2 VX
220-240 V / 60 Hz / 2 x 1.5 HP
Feet
Gal/min
Data specications
Type of current 1 phase
Voltage 220-240V
Frequency 60 Hz
Motor rating 1.5 HP
Current 12 A
Protection code Station: IP68, control box: IPX4
Shut o󰀨 head 43 ft
Max. discharge height 36 ft (2’’) / 20 ft (4’’)
Max. ow rate 125 gpm (2") or 137 gpm (4")
Max. ow rate (both motors in operation) 145 gpm (2”) or 250 gpm (4”)
Max temperature 158°F
Solids handling diameter 2"
Tank volume 31.7 gallons
Useful volume 6.8 gallons
ON / OFF level activation 180 mm /100 mm
ON alarm activation 255 mm
Weight including accessories 223 Lbs
Discharge 2" or 4"
Inlet 1-1/2" & 4"
Ventilation 2-1/2"
0
0
5
10
15
20
25
30
35
40
45
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
discharge Max 2"
discharge Max 4"
m1+m2m1
Discharge height
Flowrate
