20
FR
ANNEXES
Schéma d’encombrement SANICUBIC 1 VX
36"
29-5/8"
16"
28"
17-1/4"
7-1/2"
6-3/4"
5-5/8"
18"
8-1/8"
5"
4-5/8"
8-1/8"
2-1/2"
5"
5"
Schéma d’encombrement SANICUBIC® 2 VX
