97-6133 • Rev. 5/07
OPERATOR’S MANUAL
PRESSURE WASHER
8
OPERATING INSTRUCTIONS
STEP 1: Check fuel tank and pump
oil levels on both machines and
connect garden hose to pressure
washer. CAUTION: Only use fresh
water to this machine.
STEP 2: Attach high pressure hose
between pressure washer and ma-
chine. Turn garden hose water on.
Additional adapters and couplers
may be needed to connect your
brand of pressure washer to the
machine.
STEP 4: Connect the power cord
into the proper electrical outlet,
then push in the GFCI reset button.
Start up attached pressure washer
according to the manufacturers in-
structions. When a steady stream of
water flows from the spray gun and
wand the machine is ready for cold
water cleaning.
STEP 4: For hot water washing,
turn the machine burner switch to
the ON position. Adjust thermostat
to desired temperature setting. (The
burner will light automatically.)
Burner
Switch
