HEPA
XHF340
4
5
EMPTY THE DUST CUP
1 Pull up on the dust cup release latch and lift the dustcup off the pod.
2 Holding the dust cup over a garbage bag or can, press the bottom empty release latch.
3 Press the top dust cup release latch to access the dust screen and remove built-up debris as required. Turn the dust cup over and empty the upper chamber by
holding it by the handle on the side of the dust cup.
CLEAN THE FILTERS
See cleaning schedule on page 2
4 With the dust cup detached, remove and rinse the foam and felt filters every three months. Hand wash only. Let air dry completely before replacing. Tap loose dirt
off filters between washes as needed.
5 Once a year open the filter grill to remove and rinse the HEPA filter. Hand wash only. Let air dry completely before replacing.
MAINTENANCE
1
2
3
Foam
Felt
1229FC340
