Sharp 1118H

26
THERADS
PER
INCH
KNOB
FIRST
GEAR
1ST
GEAR
ON
STUD
2ND
GEAR
ON
STUD
SCREW
GEAR
1
DLER
THREADS
PER
INCH
KNOB
FIRST
GEAR
1ST
GEAR
ON
STUD
2ND
GEAR
ON
STUD
SCREW
GEAR
1
DLER
114 2 30* 57 22* 66 44 160 3 24 32 22* 66 44
115 2
24
46 22* 66 44 164 3 30* 41 22* 66 44
116 3 30* 29 22* 66 44 166 3 30* 33 22* 83 55*
118 2 30* 59 22* 66 44 170 3 24 34 22* 66 44
120 2 30* 60* 22* 66 40 172 3 30* 43 22* 66 44
122 2 30* 61 22* 66 44 176 3 30* 44 22* 66 44
124 3 30* 31 22* 66 44 180 3 30* 45 22* 66 44
125 2 24 50 22* 66 44 184 3 30* 46 22* 66 44
126 3 40 42 22* 66 44 188 3 30* 47 22* 66 44
128 3 30* 32 22* 66 44 190 3 24 38 22* 66 44
130 3 48 52 22* 66 30* 192 3 30* 48 22* 66 44
132 3 30* 33 22* 66 44 196 3 30* 49 22* 66 44
134 3 30* 33 22* 67 44 200 3 24 40 22* 66 44
135 3 40 45 22* 66 44 204 3 30* 51 22* 66 44
136 3 30* 34 22* 66 44 208 3 30* 52 22* 66 44
138 3 40 46 22* 66 44 210 3 24 42 22* 66 44
140 3 30* 35 22* 66 44 212 3 30* 53 22* 66 44
142 3 30* 33 22* 71 44 220 3 30* 55* 22* 66 44
144 3 40 48 22* 66 44 224 3 30* 56 22* 66 40
145 3 24 29 22* 66 44 228 3 30* 57 22* 66 44
146 3 30* 33 22* 73 44 230 3 24 46 22* 66 44
148 3 30* 37 22* 66 44 236 3 30* 59 22* 66 44
150 3 40 50 22* 66 44 240 3 30* 60* 22* 66 40
154 3 30* 33 22* 77 44 244 3 30* 61 22* 66 44
156 3 30* 39 22* 66 44 250 3 24 50 22* 66 44
※
※※
※
50 TEETH AND 127 TEETH GEARS MUST BE REMOUNTED (WITH
OUT BRACKET) TO
OBTAIN METRIC THREAD PITCHES THROUGH THE GEARBOX.
