Sharp 1118H

KEY
PARTS NUMBER
PCS
PARTS NAME
KEY
PARTS NUMBER
PCS
PARTS NAME
1 LT-03-101 1 BED BODY 33B LT-03-122B 1 BEARING SPACER
2 PD03B16B 2 PIN 34 BB72032Z 2 BEARING
3 SA05012 8 SCREW 35 LT-03-123A 1 LOCK NUT
4 LT-03-102 1 RACK 36 LT-03-124 1 LOCK NUT
5 LT-03-103 1 LEAD SCREW 37 PT3#25 1 TAPER PIN
6 LT-03-104 1
LEAD SCREW SUPPORT
38 LB-03-013 1 BED PLATE
7 PT7#64 2 TAPER PIN 39 SA08020 28 SCREW
8 SA08045 2 SCREW 39A WS08B 17 LOCK WASHER
9 RNA6902 1 NEDDLE BEARING 40 SA08025 14 SCREW
10 LT-03-105 1 SPEED LEVER 41 ORP25 4 O RING
11 LT-03-106 1 SPEED ARM 42 L-5008 2 WASHER
12 LT-03-107 1 REVERSE ARM 43 L-5010 2 SPRING WASHER
13 LT-03-108 2 FIXED BLOCK 44 NH08BF 2 NUT
14 LT-03-109 1 SWIVEL SHAFT 47 LB-03-021 3 HOLD DOWN STUD
15 RCS08 2 SNAP RING 48 LB-03-025 3 WASHER
16 PT03045 3 TAPER PIN 48A LB-03-026 3 SPACER
16A LT-03-110 1 REVERSE ARM 48B LB-03-022 10 WASHER
17 LT-03-111 4 NUT
48C
LB-03-027 3 WASHER
18 LT-03-112 1 SCREW 49 WB10B 6 WASHER
19 LT-03-113 1 GUIDE BLOCK 50 LB-03-024 3 SPRING
20 LT-03-114 1 GUIDE BAR 51 NH10BF 3 NUT
21 LT-03-115 1 LOCATING LINK 52 L-4001 2 BALL HANDLE
22 LT-03-116 1 DOWEL 53 L-5004A 2 LEVER
23 LT-03-117 1 SPRING 54 LT-03-126 1 SPEED PLATE
24 SL12020 1 LOCK SCREW 55 PD03B104B 1 PIN
25 LT-03-118 1
LENGTH CONTROL BAR
56 L-5006 1
REVERSE FORWAR PLATE
26 LT-03-119 2 DOMPER
27 SL06006 2 LOCK SCREW
28 SL05006 2 LOCK SCREW
29 SA06035 2 SCREW
30 LT-03-120 1 FIXED BLOCK
31 PT03025 1 TAPER PIN
32 LT-03-121 1
LENGTH CONTROL LEVER
33 LT-03-122 1 BEARING SPACER
33A LT-03-122A 1 BEARING SPACER
43
BED ASSEMBLY
