4
190TW8 TV
Technical Data
Display Area: 19W inches diagonal
H-Phase: A-B Less than 1.5mm
V-Center: C-D Less than 1.5mm
Tilt: E-F Less than 1mm
Speaker Internal speaker. 5W*2 stereo, volume adjustable.
Treble, Bass ( + 3db)
Frequency Response 100~15KHz with +/-3 db variation
THD(Total HarmonicDdistortion) Limited to 5 % at 2W (at 0.1~15 KHz)
OSD Capability
On screen display adjustment function
ISP Fuctions
ISP (In System Programming) function available
for revising driver easily.
Input Voltage 90 ~ 264 V , 47 ~ 63 Hz
Input Current 0.6~1.5 A
Max. Power 58 Watts
PC saving Power 2Watts Max
Stand-By Power(AV,TV) 1 Watts Max.
Tilt 0~15
VESA Mount 100*100 mm
Mechanical
Display Area & Tilt
Audio
Power Source
A
E
D
C
F
B
1.2 Input & Output Signal Specification
Type Analog
Polarity Positive
Level 1Vp-p ( with Sync.)
Impedance
75£[±5%
Interface RCA jack, Yellow color
Type Analog
Polarity Positive
Level Y : 1Vp-p ( with Sync.) , C : 0.286Vp-p
Impedance
75£[±5%
Interface DIN Jack
Type Analog
Polarity Positive
Impedance
75£[±5%
Interface 21 Pin Euro-SCART
Type Stereo R/L Channels
Level 500mVrms
Impedance
More than 22k£[
Interface RCA Jack
Right channel Red color.
Left Channel White color
Type Stereo R/L Channels
Level 1Vrms
Impedance
More than 22k£[
Interface
3.5mm Stereo Jack , Black color
Type Stereo R/L Channels
Level 40mW rms/per Channel(typ.) for 32 ohm earphon
Impedance 32 ohm
Interface 3.5mm Stereo Jack
Max. Audio output 5W + 5W (at 1.0Vp-p / 1kHZ input,10% THD ma
x
Sound Distortion 1% THD max. ( at 250mW/1kHZ : )
Speaker 5 W / 8 ohms
Speaker Impedance8 ohms at 1kHZ
Residual Hum 500uW Max.( at Min. Volume : )
Max. Hum 1000uW Max ( at Max. Volume )
CVBS Input
S-Video Input
SCART Input
Audio Input
PC Stereo Input
Headphone Output
Built-in Speaker
Type Stereo R/L Channels
Level 400Vrms.
Interface 3.5mm Stereo Jack
Input Impedance 75 ohms
Frequency Range 48.25~855.25 MHz (PAL)
Video S/N Ratio 45 d B (Typical)
AudioS/NRatio 63dB(Typical)
Sync Level : Low = 0 to 0.8V, High = 2.0 to 5 V
Polarity : Positive or Negative
Impedance : 1 k ohm or higher
RGB Signal Level : 0 to 700mV Positive
Impedance : 75£[±5%
1
Red Video
2
Green Video
3
Blue Video
4
Ground
5
Ground
6
Red Ground
7
Green Ground
8
Blue Ground
9+5V(PC97)
10 VGA-CONN(Sync GND)
11 Ground
12 SDA ( DDC Data )
13 Horizontal Sync
14 Vertical Sync
15 SCL ( DDC Clock )
Type Type A
Level 400mVrms
Impedance
100£[
Type RCA Jack
Level 500mVpp +- 20%
VGA Input
D-Sub Pin Define
HDMI
SPDIF
Audio Line Output
RF Input
