4. Input/Output Signal Specication
CVBS Input Type Analog
Polarity Positive
Level 1Vp-p ( with Sync.)
Impedance 75Ω± 5%
Interface RCA jack, Yellow color
S-Video Input Type Analog
Polarity Positive
Level Y : 1Vp-p ( with Sync.) , C : 0.286Vp-p
Impedance 75Ω± 5%
Interface DIN Jack
SCART Input Type Analog
Polarity Positive
Impedance 75Ω± 5%
Interface 21 Pin Euro-SCART
Audio Input Type Stereo R/L Channels
Level 500mVrms
Impedance More than 22kΩ
Interface RCA Jack
Right channel Red color.
Left Channel White color
PC Stereo Input Type Stereo R/L Channels
Level 1Vrms
Impedance More than 22kΩ
Interface 3.5mm Stereo Jack , Black color
Headphone
Output Type Stereo R/L Channels
Level 40mW rms/per Channel(typ.) for 32 ohm earphone
Impedance 32 ohm
Interface 3.5mm Stereo Jack
Built-in Speaker Max. Audio output 5W + 5W (at 1.0Vp-p / 1kHZ input,10% THD max.)
Sound Distortion 1% THD max. ( at 250mW/1kHZ : )
Speaker 5 W / 8 ohms
Speaker Impedance 8 ohms at 1kHZ
Residual Hum 500uW Max.( at Min. Volume : )
Max. Hum 1000uW Max ( at Max. Volume )
Audio Line Output Type Stereo R/L Channels
Level 400Vrms.
Interface 3.5mm Stereo Jack
RF Input Input Impedance 75 ohms
Frequency Range 48.25~855.25 MHz (PAL)
Video S/N Ratio 45 d B (Typical)
Audio S/N Ratio 63 d B (Typical)
VGA Input Sync Level : Low = 0 to 0.8V, High = 2.0 to 5 V
Polarity : Positive or Negative
