Sharp 190TW8FB

Impedance : 1 k ohm or higher
RGB Signal Level : 0 to 700mV Positive
Impedance : 75Ω± 5%
D-Sub Pin Define 1
Red Video
2
Green Video
3
Blue Video
4
Ground
5
Ground
6
Red Ground
7
Green Ground
8
Blue Ground
9 +5V ( PC97 )
10 VGA-CONN(Sync GND)
11 Ground
12 SDA ( DDC Data )
13 Horizontal Sync
14 Vertical Sync
15 SCL ( DDC Clock )
05/25 TVI update
HDMI Type Type A
Level 400mVrms
Impedance 100Ω
SPDIF Type RCA Jack
Level 500mVpp +- 20%
79 190TW8 TV
