11 NORMAL Key (1) Once in PICTURE or SOUND Mode, and the NORMAL key is pressed,
*Note:
all the settings will be preset to normal setting accordingly . In NORMAL Mode, when press NORMAL key,
(Normal setting value for every AV mode : NEWS/MUSIC/MOVIE) will appear NORMAL OSD and all setting
PICTURE MODE
NEWS MUSIC MOVIE
PICTURE, SOUND functions set to NORMAL.
CONTRAST 55 60 60
COLOUR 0 0 +3
BRIGHTNESS 0 0 0
TINT CENTER CENTER CENTER
SHARPNESS 0 0 +3
PICTURE NR OFF OFF OFF
WHITE TEMP Mid Mid Mid
SOUND MODE
SURROUND OFF OFF OFF
BALANCE 0 0 0
AVL ON ON ON
EQUALIZER MENU
* Bar indicator display 0~20
100 10 14 14
300 10 9 8
1K 12 7 9
3K 11 8 8
8K 10 12 11
12 COLOUR SYSTEM (1) Receive the "PAL COLOUR BAR" signal, press MENU, choose CH-SETTING to
select COLOR modes except PAL, check the COLOUR is not working properly.
Then, select the "PAL" mode. Check again its colour so that it is working properly.
(2) Receive "SECAM COLOUR BAR" signal, press MENU, choose CH-SETTING to
select COLOR modes except SECAM, check the COLOUR is not working properly.
Then, select the "SECAM" mode. Check again its colour so that it is working
properly.
(3) Receive "NTSC 4.43" signal, press MENU, choose CH-SETTING to
select COLOR modes except N443, check the COLOUR is not working properly.
Then, select the N443 mode. Check again its colour so that it is working properly.
(4) Receive "NTSC 3.58 COLOUR BAR" signal , press MENU, choose
select COLOR modes except N358, check the COLOUR is not working properly.
Then, select the N358 mode. Check again its colour so that it is working properly
13 SOUND SYSTEM (1) Receive "PAL-D/K" signal, press MENU, choose CH-SETTING then go into SOUND
mode to select B/G, I Check the sound output is not working properly.
Select D/K and check the sound output to make sure it is working properly.
(2) Receive "PAL-I" signal, press MENU, choose CH-SETTING then go into SOUND
mode to select B/G, D/K. Check the sound output is not working properly.
Select I and check the sound output to make sure it is working properly.
mode to select I, D/K. Check the sound output is not working properly.
Select B/G and check the sound output to make sure it is working properly.
(4) Receive "NTSC3.58 -M" signal, press MENU, choose CH-SETTING then go into
SOUND mode to select I, D/K. Check the sound output is not working properly.
Select M and check the sound output to make sure it is working properly.
14 NOISE MUTE (1) Receive "PAL COLOUR BAR" signal.
CHECKING (2) Turn up the volume control to maximum, make sure the sound is
heard from the speakers. Then put the unit in no signal state.
(3) Check the sound mute is effective.
(4) Finally turn sound level of CTV to minimum.
15 OSD LANGUAGE (1) Check OSD LANGUAGE quantity and type for respect model.
QUANTITY CHECK
MODEL QUANTITY ENGLISH
