Sharp 27L-S500 - Page 11

11
27L-S500,27L-X2000
CL27S50,CL27X200
S39 C-DECODE 0 ~ 255 161 161 ” ”
S40 OSD POSITION 0 ~ 15 11 ” C.C. display positioning
S41 ENERGY SAVE 0 ~ 31 10 0 ” VCJ IC (IC401) adjusted
S42 VIDEO TINT 0 ~ 63 26 ” ”
M01 INPUT LEVEL (ATT) 0 ~ 15 7 ” MTS IC (IC3001) adjusted
M02 MTS VCO 0 ~ 63 37 ” ”
M03 FILTER 0 ~ 63 30 ” ”
M04 WIDE BAND 0 ~ 63 35 ” ”
M05 SPECTRAL 0 ~ 63 22 ” ”
P01 PIP Y-LEVEL(CONTRAST) 0 ~ 127 43 ” P-IN-P adjusted
P02 PIP TINT (TINT) 0 ~ 63 41 41 ” ”
P03 PIP COLOR(COLOR_SAT) 0 ~ 127 55 RF signal input (TUNER-B) P-IN-P adjusted
P04 Y-OFFSET(Y_OFFSET) 0 ~ 31 9 9 ” ”
P05 PIP H-POSI(HXA) 0 ~ 255 10 10 ” ”
P06 BGP(HADJ) 0 ~ 15 0 0 ” ”
P07 FREE RUN(FREE_RUN_ADJ) 0 ~ 15 11 11 ” ”
C01 PICTURE-C(SUB CONTRAST) 0 ~ 31 20 13 Component signal input VCJ IC (IC401) adjusted
C02 TINT-C 0 ~ 27 21 21 ” ”
C03 COLOR-C(SUB COLOR) 0 ~ 31 15 3 ” ”
C04 BRIGHT-C(BRIGHTNESS) 0 ~ 101 58 ” ”
C05 SHARP-C(SHARPNESS) 0 ~ 27 0 0 ” ”
C06 V-POSITION-C 0 ~ 7 0 0 ” ”
C07 H-POSITION-C 0 ~ 31 19 ” ”
C08 R CUT-OFF-C 0 ~ 255 64 ” ”
C09 G CUT-OFF-C 0 ~ 255 64 ” ”
C10 B CUT-OFF-C 0 ~ 255 64 ” ”
C11 G(R) DRIVE-C 0 ~ 127 64 ” ”
C12 B DRIVE-C 0 ~ 127 64 ” ”
C13 VSM GAIN-C 0 ~ 3 2 3 ” ”
C14 COMP. C-DECODE 0 ~ 255 105 105 ” ”
SERVICE
No.
VARIABLE
DATA RANG
INITIAL
VALUE
FIXED
VALUE
CONTROL DESTINATION
INPUT CONDITIONS
ADJUSTMENT ITEM
Only for
Models
27L-X2000,
CL27X200
Note 1 : This item is used only at the manufacturing factory.
Do not change the data. (If this setting is changed to "1", the adjustment data may get wrong.)
Table - A
