12
27L-S500,27L-X2000
CL27S50,CL27X200
I01 E-SOUND 0 / 1 0 1
I02 DSE 0 / 1 0 0
I03 SRS 0 / 1 0 1
I04 SRS 32/36, 27 (27) 0 / 1 (32/36) 0 0
I05 A/V IN 3/2 (2) 0 / 1 (3) 0 1
I06 V-CHIP 0 / 1 1 1
I07 PinP 0 / 1 1 1
I08 COMPONENT 0 / 1 0 1
I09 ENGL/ESPA (ESPA) 0 / 1 (ENGL) 1 1
I10 DSE SHIPPED POSITION (OFF) 0 / 1 (MID) 0 0
SERVICE
NUMBER
27L-S500, CL27S50 27L-X2000,CL27X200
ADJUSTMENT CONTENTS
Table - B
RANGE
ADJUSTMENT ITEM
NECESSARY
UNNECESSARY
ADJUSTMENT
NOTES
PART REPLACED
Holding down both the CH-up/down buttons on the TV set at service mode for more than 2 seconds will automatically
write the above initial values into IC1501.
The adjustment is needed to compensate for characteristics
of parts including IC401.
Data is stored in IC1501.
X
IC2001
Holding down both the CH-up/down buttons on the TV set in
the service mode for more than 2 seconds will automatically
write the above initial values into IC1501. Then perform a
complete adjustment.
Adjust items related to MTS only (M01~M05).
Adjust items related to picture tube only.
Adjust items related to P-IN-P only (P01~P07).
CRT
IC3001
IC1801
X
X
Table - C
IC1501
X
IC401
X
X
