Sharp 27R-S100 - Using the Video and Audio Input Jacks

39
DVD
CAMCORDER
TV GAME
VCR
(Front connection
terminals of TV)
To AUDIO OUTPUT (R)
To AUDIO OUTPUT (L)
To VIDEO
OUTPUT
FWDREV
(Rear connection
terminals of TV)
To AUDIO OUTPUT (L)
To AUDIO OUTPUT (R)
V
I
D
E
O
I
N
2
L
-
A
U
D
I
O
-
R
To VIDEO OUTPUT
Using the Video and Audio Input Jacks
VIDEO EQUIPMENT
L Connecting video equipment for playback of video material.
• When the television is connected to video equipment as shown below, the material being played
back on the video equipment can be seen on the television screen.
Connecting video device equipped with video output terminals.
CONNECTIONS
39-40 27R-S100.p65e 11/4/01, 11:44 AM39
