Sharp 4T-C60AH1X - [1] PRINTED WIRING BOARD ASSEMBLIES; Printed Wiring Board Assemblies List; [2] LCD PANEL; LCD Panel Module Units

4T-C6070AH1X
2
[1] PRINTED WIRING BOARD ASSEMBLIES
N DKEYMG924FM01 V MAIN UNIT (GENERAL) 4T-C60AH1X
N DKEYMG924FM02 V MAIN UNIT (GENERAL) 4T-C70AH1X
N RUNTKB748WJQZ V POWER UNIT 4T-C60AH1X
N RUNTKB749WJQZ V POWER UNIT 4T-C70AH1X
N RUNTKB731WJQZ V KEY UNIT 4T-C60AH1X
N RUNTKB732WJQZ V KEY UNIT 4T-C70AH1X
N RUNTKB751WJQZ V WIFI + BT UNIT 4T-C60AH1X
N RUNTKB707WJQZ BB V WIFI + BT UNIT 4T-C70AH1X
N DUNTKG498FM02 V LED/ IR UNIT
[2] LCD PANEL
N KSETLA751WJ20 V 60" LCD PANEL MODULE UNIT
N KSETLA752WJ20 V 70" LCD PANEL MODULE UNIT
[3] MAIN UNIT ( DKEYMG924FM01/02 ) 4T-C60/70AH1X
IC 3101 RH-IXE112WJQZQ BB V KLM4G1FETE-B041
SC 3801 QCNCWB143WJQZY AK V CONNECTOR
LUG3301 QEARBA062WJZZY AD V GROUND-PART
SC 0501 QJAKEA145WJN1Q V JACK
J 0503 QJAKJA054WJQZY AD V JACK
J 2201 QJAKZA159WJQZQ AR V JACK
P 1701 QPLGNB092WJZZY AD V PLUG
P 0502 QPLGNB149WJZZY AC V PLUG
P 2001 QPLGNB150WJZZY AC V PLUG
P 2002 QPLGNB211WJZZY V PLUG
P 3801 QPLGNB242WJZZY AD V PLUG
P 0501 QPLGNB257WJZZY AC V PLUG
P 9601 QPLGNB360WJZZY AD V PLUG
J 0501 QSOCZA370WJQZY AD V SOCKET
SC 1501 QSOCZA390WJQZY AE V SOCKET
SC 1502 QSOCZA390WJQZY AE V SOCKET
J 0502 QTANJA159WJPZQ AF V TERMINAL
FB 0506 RBLN-0104TAZZY AB V BALUN
FB 0507 RBLN-0104TAZZY AB V BALUN
FB 0503 RBLN-0244TAZZY AB V BALUN
FB 1701 RBLN-A371WJQZY AB V BALUN
FB 1702 RBLN-A371WJQZY AB V BALUN
FB 1703 RBLN-A371WJQZY AB V BALUN
FB 1704 RBLN-A371WJQZY AB V BALUN
FB 3191 RBLN-A371WJQZY AB V BALUN
FB 0501 RBLN-A589WJQZY AA V BALUN
FB 0502 RBLN-A589WJQZY AA V BALUN
FB 3829 RBLN-A589WJQZY AA V BALUN
FB 3830 RBLN-A589WJQZY AA V BALUN
FB 9601 RBLN-A589WJQZY AA V BALUN
FB 9602 RBLN-A589WJQZY AA V BALUN
FB 9604 RBLN-A589WJQZY AA V BALUN
FB 9606 RBLN-A589WJQZY AA V BALUN
FB 9607 RBLN-A589WJQZY AA V BALUN
FB 9608 RBLN-A589WJQZY AA V BALUN
FB 9609 RBLN-A589WJQZY AA V BALUN
FB 9616 RBLN-A589WJQZY AA V BALUN
FB 3302 RBLN-A592WJQZY AH V BALUN
FB 3303 RBLN-A592WJQZY AH V BALUN
FB 3304 RBLN-A592WJQZY AH V BALUN
FB 3305 RBLN-A592WJQZY AH V BALUN
FB 3306 RBLN-A592WJQZY AH V BALUN
FB 3307 RBLN-A592WJQZY AH V BALUN
FB 3308 RBLN-A592WJQZY AH V BALUN
FB 3309 RBLN-A592WJQZY AH V BALUN
FB 3310 RBLN-A592WJQZY AH V BALUN
FB 3311 RBLN-A592WJQZY AH V BALUN
FB 3312 RBLN-A592WJQZY AH V BALUN
FB 3313 RBLN-A592WJQZY AH V BALUN
FB 3314 RBLN-A592WJQZY AH V BALUN
FB 0510 RBLN-A593WJQZY AA V BALUN
FB 0511 RBLN-A593WJQZY AA V BALUN
FB 0513 RBLN-A593WJQZY AA V BALUN
FB 0514 RBLN-A593WJQZY AA V BALUN
FB 1105 RBLN-A593WJQZY AA V BALUN
FB 1106 RBLN-A593WJQZY AA V BALUN
FB 2001 RBLN-A593WJQZY AA V BALUN
FB 2002 RBLN-A593WJQZY AA V BALUN
FB 2003 RBLN-A593WJQZY AA V BALUN
FB 2004 RBLN-A593WJQZY AA V BALUN
FB 2005 RBLN-A593WJQZY AA V BALUN
FB 2006 RBLN-A593WJQZY AA V BALUN
FB 2007 RBLN-A593WJQZY AA V BALUN
FB 3301 RBLN-A593WJQZY AA V BALUN
FB 3801 RBLN-A593WJQZY AA V BALUN
FB 3802 RBLN-A593WJQZY AA V BALUN
FB 3803 RBLN-A593WJQZY AA V BALUN
FB 3804 RBLN-A593WJQZY AA V BALUN
FB 3805 RBLN-A593WJQZY AA V BALUN
FB 3806 RBLN-A593WJQZY AA V BALUN
FB 3807 RBLN-A593WJQZY AA V BALUN
FB 3808 RBLN-A593WJQZY AA V BALUN
