Sharp AH-A09BF User Manual

PART NAMES
1 Inlet (Air)
2 Open Panel
3 Air Filters
4 AUX. Button
5 Receiver Window
6 Power Supply Cord
7 Indicator Panel
8 Vertical Adjustment Louvres
9 Horizontal Adjustment Louvres
0 Outlet (Air)
q Remote Control
w FAN SPEED Lamp
e TIMER Lamp (orange )
r OPERATION Lamp (red )
OUTDOOR UNIT
NOTE: Actual units might vary slightly from those shown above.
INDOOR UNIT
1
2
3
4
5
6
7
8
9
0
q
t Inlet(Air)
y Refrigerant Tube and
Interconnecting Cord
u Drainage Hose
i Outlet(Air)
4
w
e
r
t
y
u
i
LOW HIGH

Sharp AH-A09BF Specifications

General

Brand	Sharp
Model	AH-A09BF
Category	Air Conditioner
Language	English
