Sharp AH-A09BF - Remote Control; Transmitter Layout and Display

REMOTE CONTROL
1 TRANSMITTER
2 DISPLAY (Liquid Crystal Display)
3 ON/OFF Button
4 THERMO. (Thermostat) Button
5 DISPLAY Button
6 MODE Button
7 TIMER ON Button (for setting the timer)
8 ONE-HOUR OFF TIMER Button
9 TIMER OFF Button (for setting the timer)
0 FAN Button
q TIMER CANCEL Button
w SWING Button
5
e MODE SYMBOLS
: AUTO : COOL
: DRY
r FAN SPEED SYMBOLS
: AUTO : Manual setting
t TEMPERATURE AND TIMER COUNT DOWN
INDICATOR
y TRANSMITTING SYMBOL
u TIMER ON/TIMER OFF INDICATOR
Indicates when timer on or timer off is set.
L.C.D. REMOTE CONTROL DISPLAY
1
2
3
4
5
6
7
8
9
0
q
w
e
r
t
y
u
MODE
DISPLAY MODE
FAN1H
SWING
CANCEL
TEMP.
TEMP.
FAN TIMER
