CHAPTER 2. ELECTRIC CIRCUIT
[1] ELECTRIC PARTS
1. INDOOR UNIT (AH-MP20)
PART NO. PART NAME ITEM
SPECIFICATION
1
Terminal Board Rating
300V,25A
2
Fan motor Capacitor Rating
450V, 2
µF
3
Relay-1 Rating
AC250V,20A
(RY1)
Coil Volt: 12V
4
Printed Wiring Board Material
Paper Base Phenolic Resin (UL 94V-0)
5
Transformer Rating
Pri 220-240VAC
6
Fan motor Rating
220 - 240VAC 50Hz 41W 4-Pole
Type
MLA999
Thermal Protector
Cut off 135 10 C
(Internal)
7
Power Supply Cord Rating
3 x 1.5 mm2
Type
H05VV-F
8
Louver Motor Rating
DC12V
Type
24BYJ48
1. OUTDOOR UNIT (AU-MP20)
PART NO. PART NAME ITEM
SPECIFICATION
1
Terminal Board Rating
300V,25A
2
Fan motor Capacitor Rating
450V, 3
µF
3
Running Capacitor Rating
400V, 45
µF
4
Compressor Rating
AC220V 50Hz 1730W
Type
PH31VNET
5
Protector Rating
-
Type
(INTERNAL)
6
Fan motor Rating
220 - 240VAC 50Hz 71W 6-Pole
Type
MLA002
Thermal Protector
Cut off 135 5 C
(Internal)
5
±
°
±
°
