Sharp AH-N45DP2 User Manual

28
AH-N45DP2
AU-N45DP2
AH-N56DP2
AU-N56DP2
1
2
3. Remove the connector of Louver motor and take
off the Wire and Holder.
4. Push the one of the Vertical louver.
How to remove the DISPLY COVER.
1 Push the center of the Front panel under
the Display cover.
2 Slide it to one side.
How to remove the Hi Voltage UNIT.
1. Remove 2 screws fixing Holder.
2. Take off the HIGH VOLTAGE UNIT ASS’Y from
the HOLDER
3. Remove the connector of HIGH VOLTAGE UNIT
ASS’Y
