Sharp AH-XP Series - PART NAMES; INDOOR UNIT

EN-3
INDOOR UNIT
9
10
11
Premium models Standard models
1
2
3
4
5
6
7
8
9
10
1
Inlet (Air)
2
Open Panel
3
Air Filter
4
AUX Button
5
Receiver Window
6
Vertical Airow Louver
7
Horizontal Airow Louver
8
Outlet (Air)
9
OPERATION Lamp (Green/Blue )
10
TIMER Lamp (Orange )
11
WLAN Lamp
(Green )
Indoor unit apperance may be different from the image above.
※
