INDOOR UNIT
OUTDOOR UNIT
13 Inlet (Air)
14 Refrigerant Pipe and Cable
15 Drainage Hose
16 Outlet (Air)
AU-X10UXD, AU-X13UXD
AU-XP10UF, AU-XP15UF, AU-XS10UF, AU-XS15UF
AU-XP20UF, AU-XS20UF AU-XP25UF, AU-XS25UF
13
14
15
16
13
14
15
16
10
11
Standard models Premium models
1
2
3
4
5
6
7
8
9
10
11
12
1 Inlet (Air)
2 Open Panel
3 Air Filter
4 AUX Button
5 Receiver Window
6 Vertical Airow Louver
7 Horizontal Airow Louver
8 Outlet (Air)
9 Lighting bar
(For XP10/13UXD,
XP10/15UF models only)
10 OPERATION Lamp
(green
)
11 TIMER Lamp (orange
)
12 PLASMACLUSTER Lamp
(blue
)
(For Premium models only)
13
14
15
16
PART NAMES (UNIT)
