Sharp AL-1631 Parts Manual

q
PARTS GUIDE
CONTENTS
Because parts marked with "! " is indispensable for the machine safety maintenance and poeration, it must
Be replaced with the parts specific to the product specification.
SHARP CORPORATION
This document has been published to be used for
after sales service only.
The contents are subject to change without ontice.
CODE:00Z AL1641CSP1
DIGITAL LASER COPIER /
DIGITAL MULTIFUNCTIONAL SYSTEM
AL-1631
AL-1641CS
MODEL
AL-1645CS
(For North America and LAG2)
(AL-1641CS)
1
Exteriors
2
Original cover unit (AL-1645CS)
5
SPF exteriors (AL-1631/AL1641CS)
6
SPF transport unit (AL-1631/AL1641CS)
7
RSPF SPF pick up unit
(AL-1631/AL1641CS)
8
Operation panel
9
Side door unit
F
Optical frame
G
LSU unit
H
Delivery paper guide unit
I
Middle frame
J
Base plate unit 1
K
Base plate unit 2
L
Fusing unit
M
Drive unit
O
Multi manual paper feeding cover unit
Q
Multi manual paper feeding unit
T
250 sheets tray
U
Harness
X
Packing material & accessories
Y
Operation PWB
Z
MCU PWB
■
Index
The AL-1645CS/AL-1641CS/AL-1631 Parts Guide describes
only changed from AL-1215/AL-1530CS/AL1540CS/
AL-1551CS Parts Guide.
For the common parts, please refer to the
AL-1215/AL-1530CS/AL1540CS/AL-1551CS Parts Guide
(Code: 00ZAL1551CSP1)
[Note]
MODEL
1
2
3
AL-1645CS
AL-1641CS
AL-1631
AL-1215
AL-1530CS
AL-1540CS
AL-1551CS
Reference MODEL
