Command table
How to read the command table
Command:
Direction:
Command field
W When the “Parameter” is set in the parameter field, the command functions as described under “Control/Response Contents”.
?” in the
R The returned value indicated under “Reply” can be obtained by setting “????” or parameter field.
Power control/Input mode selection
Picture menu
Function Command Direction Parameter Reply Control Response content Remarks
POWER CONTROL POWR
W
0 Switch to standby mode
Power on function is available only in RS-232C connection
with 9600 baud.
Use WoL function when using IP connection.
When the TV is powered off via RS232C, please wait
approx. 30 seconds before sending the power on
command.
1 Return from standby mode
R 1 Normal mode
"0" (standby mode) and "2" (input signal waiting mode) are
not available on the display.
INPUT MODE
SELECTION
INPS WR 0~6 0~6
TV = 0
AV = 1
HDMI1 = 2
HDMI2 = 3
HDMI3 = 4
USB = 5
HOME =6
Function Command Direction Parameter Reply Control Response content Remarks
BRIGHT VLMP WR 1~100 1~100
COLOR MODE BMOD WR 0~10 0~10
7 : Standard
9 : Movie
10 : Game
2 : PC
3 : Dynamic
4 : Dynamic(Fixed)
0 : User
SIZE WIDE WR 1~7 1~7
1 : Auto
2 : Normal
3 : Zoom
4 : Dot by Dot
5 : 4:3
6 : 14:9
7 : 16:9
8 : Letterbox
9 : Panorama
In each case, display mode will be changed to "normal" when
video source has changed and unable to adopt current
display mode.
Function Command Direction Parameter Reply Control Response content Remarks
VOLUME VOLM WR 1~100 1~100
MUTE AUDIO MUTE WR 0-1 0-1 0 MUTE_OFF 1 MUTE_ON
MODEL INF1 R
SERIAL NO SRNO R
Usage Time UTIM WR
MAIN firmware version FMVR R
MAC address RMAC R
RESET RSET W
Others menu
