Item 4P-B43EJ2U 4P-B50EJ2U 4P-B55EJ2U 4P-B65EJ2U
LCD Panel
43" Class
(42 33/64" Diagonal)
50" Class
(49 33/64" Diagonal)
55" Class
(54 33/64" Diagonal)
65" Class
(64 17/32" Diagonal)
Resolution
8,294,400 pixels (3840 x 2160)
Video color system
NTSC-M/PAL-N/PAL-M
TV
Function
TV
- Standard (CCIR)
American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF
VHF 2-13ch, UHF 14-69ch
CATV
1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable*1 (64/256
QAM)
1-135ch (non-scrambled channel only)
STEREO/BILINGUAL
BTSC system
Audio amplifier
8 W x 2
Terminals
Antenna terminal
ANTENNA/CABLE IN (Antenna
input)
75Ω Unbalance, F Type x 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
SERVICE ONLY Ø3.5 mm jack
Ø3.5 mm jack
INPUT 1 (ARC) HDMI
HDMI (HDMI input), ARC
INPUT 2 HDMI
HDMI (HDMI input)
INPUT 3 HDMI
HDMI (HDMI input)
AV IN (INPUT 3)
AUDIO in, VIDEO in
AUDIO OUT
AUDIO out, Headphone (Ø3.5 mm stereo)
USB 1
Photo/Music/Video mode, Software update
USB 2
Photo/Music/Video mode, Software update
EX
-IR External IR receiver connector
ETHERNET (10/100 BASE
-T)
Network connector
OSD language
English/French/Spanish
Power Requirement
AC 120 V, 60 Hz
Power Consumption
98W 130W 130W 180W
Dimensions with stands
958 x 226 x 612 mm 1112 x 243 x 672 mm 1228 x 243 x 742 mm 1446 x 285 x 870 mm
Dimensions without stands
958 x 72 x 558 mm 1112 x 70 x 642 mm 1228 x 73 x 711 mm 1446 x 73 x 835 mm
Weight/Weight without stands
6.9 kg/6.6 kg 10.0 kg/9.8 kg 13.0 kg/12.8 kg 16.8 kg/16.4 kg
Operating temperature
0°C to +40°C
*1 Emergency alert messages via Cable are unreceivable.
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification
figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
• Continuous operating time and warranty. This product is designed for a maximum daily use of 16 hours. Continual use in excess of 16 hours per day is not covered by the warranty.
NOTE
• Installing the Liquid Crystal Television requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. SHARP
bears no responsibility for improper mounting or mounting that results in accident or injury.
• Carefully read the instructions that come with the bracket before beginning work.
en-US 65
TV (4P-B43EJ2U /4P-B50EJ2U / 4P-B55EJ2U / 4P-B65EJ2U)
Specifications

Sharp AQUOS 4P-B43EJ2U Specifications

General

Brand	Sharp
Model	AQUOS 4P-B43EJ2U
Category	LCD TV
Language	English
