Item 4W-B55FT5U 4W-B65FT5U 4W-B75FT5U 4W-B86FT5U
LCD Panel
55" Class
(54 33/64" Diagonal)
65" Class
(64 17/32" Diagonal)
75" Class
(75" Diagonal)
86” Class
(85 9/16" Diagonal)
Resolution
8,294,400 pixels (3840 x 2160)
Video color system
NTSC-M/PAL-N/PAL-M
TV
Function
TV
- Standard (CCIR)
American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF
VHF 2-13ch, UHF 14-69ch
CATV
1-135ch (non-scrambled channel only)
Digital Terrestrial Broadcast
(8VSB)
2-69ch
Digital cable*1 (64/256 QAM)
1-135ch (non-scrambled channel only)
STEREO/BILINGUAL
BTSC system
Audio amplifier
8 W x 2
Terminals
Antenna terminal ANTENNA/CABLE IN
(Antenna input)
75Ω Unbalance, F Type x 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
SERVICE ONLY Ø3.5 mm jack
Ø3.5 mm jack
INPUT 1 (ARC) HDMI
HDMI (HDMI input), ARC
INPUT 2 HDMI
HDMI (HDMI input)
INPUT 3 HDMI
HDMI (HDMI input)
AV IN (INPUT 3)
AUDIO in, VIDEO in
AUDIO OUT
AUDIO out, Headphone (Ø3.5 mm stereo)
USB 1
Photo/Music/Video mode, Software update
USB 2
Photo/Music/Video mode, Software update
EX
-IR External IR receiver connector
ETHERNET (10/100 BASE
-T)
Network connector
Interactivity
Touch Technology
IR (infrared blocking detection method)
PC Connection Port
USB Type Cx 1 (a USB cable and a C-to-A adapter included)
Multi Touch
20 points
Protection Glass
Thickness: Approx. 4.0mm Shock resistance: 130 cm
OSD language
English/French/Spanish
Power Requirement
AC 120 V, 60 Hz
Power Consumption
130W 180W 300W 380W
Dimensions
1,264.5 x 83.7 x 749.3 mm 1,483.6 x 83.6 x 872.8 mm 1,705.9 x 87.5 x 996.2 mm 1,955.1 x 105.5 x 1,143.2 mm
Weight
23.4 kg 31.3 kg 51 kg 68.2 kg
Operating temperature
0°C to +40°C
*1 Emergency alert messages via Cable are unreceivable.
• As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification
figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
• Continuous operating time and warranty. This product is designed for a maximum daily use of 16 hours. Continual use in excess of 16 hours per day is not covered by the warranty.
NOTE
• Installing the Liquid Crystal Television requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. SHARP
bears no responsibility for improper mounting or mounting that results in accident or injury.
• Carefully read the instructions that come with the bracket before beginning work.
en-US 67
