Part Names of Main Unit (Continued)
Terminals
Carrying handle
Rear View
COMPONENT
ANT. (Antenna terminal)
POWER INPUT terminal
(DC 13V)
Y
AUDIO (L)
AUDIO (R)
PB (CB)
P
R (CR)
AUDIO (R)
AUDIO (L)
VIDEO
AV-IN1
AV-IN2
AV-IN3/OUT
AUDIO (R)
AUDIO (L)
VIDEO
AUDIO (R)
AUDIO (L)
VIDEO
S-VIDEO
How to fix the cables
• Secure cables and cords with the supplied cable
clamps so that they do not get caught when
mounting the cover.
Cable clamps
Pull down the hook
to open the cover.
