Preparation
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of
the types of connections that are used for a coaxial cable. If your outdoor antenna uses
a 75-ohm coaxial cable with an F-type connector, plug it into the antenna terminal at the
rear of the TV set.
rl,
2,
A 75-ohm system is generally a round
cable with F-type connector that can
easily be attached to a terminal without
tools (Commercially available).
A 300-ohm system is a flat "twin-lead"
cable that can be attached to a 75-ohm
terminal through a 300/75-0hm adapter
(Commercially available).
_F-type connector
75-ohm coaxial cable
(round)
300-ohm twin-lead cable (flat)
When connecting the RF cable to the TV set,
do not tighten F-type connector with tools.
If tools are used, it may cause damage to
your TV set. _he breaking of internal circuit,
etc.)
,_ _\ F-typeconnector
75-ohm coaxialcable
r
Connecting Antenna
• Connect the antenna cable to the TV using one of the methods in the illustrationas
shown (1 ,2 ,3 or4 ).
(_ Cable without a CATV converter
Cable TV lead--In
VHF/UHF antenna
15-ohm coaxial cable (round)
(_) Combination VHF/UHF antenna
_/5-ohm coaxial cable (round)
Home Antenna
terminal (75--ohm)
Coaxial cable
(commercially available)
Home Antenna
terminal (75--ohm)
I_@E__-
Coaxial cable
(commercially available)
@ Separate VHF/UHF antenna
,_ ANT/CABLE 1
Combiner
(commercially available)
To TV antenna terminal
To Next Page
