14
Preparation
Connecting a STB (Satellite, Cable, etc.)
You can use the INPUT 1/INPUT 2/ INPUT 3 (HDMI) or INPUT 5/INPUT 6 terminals when connecting to a STB
(Satellite, Cable, etc.) and other audiovisual equipment.
Connecting a PC
You can use the INPUT 7 (PC) terminal when connecting to a PC.
PC
When using HDMI cable
(commercially available)
When using component cable
(commercially available)
R – AUDIO – L
Y
PB
(CB)
P
R
(CR)
STB
(Set Top Box)
STB
(Set Top Box)
52D77X.indb 1452D77X.indb 14 2/17/09 5:13:06 PM2/17/09 5:13:06 PM
