Part Names
OPC indicator
(See page 18.)
OPC sensor
* (See page 18.)
POWER indicator
(See page 12.)
Remote control sensor
*1
*2
*3
*1
AC INPUT
terminal
Volume
buttons
(VOL
k
/
l
)
POWER
button
MENU
button
INPUT
button
Channel
buttons
(CH
U
/
V
)
INPUT 3
terminals
SERVICE
terminal
INPUT 5
terminal
(HDMI)
RS-232C terminal
DIGITAL AUDIO
OUTPUT terminal
INPUT 7 terminal
(HDMI)
INPUT 8 terminal
(HDMI)
Antenna/Cable in
INPUT 1 terminals
INPUT 2 terminals
OUTPUT
terminals
INPUT 6 terminal (HDMI)
INPUT 4 terminal (PC-IN)
AUDIO terminal (shared for INPUT 4 and INPUT 6) *4
*1 See page 11 for external equipment connection.
*2 See pages 14 and 17 for button operations.
*3 See page 8 for connecting the AC cord.
*4 See page 24 for details on the PC Audio Select function.
* OPC: Optical Picture Control
TV (Rear/Side)
