Sharp AQUOS LC-60E88UN - Connecting an Audio Amplifi er

14
Connecting to External Equipment
Connecting an Audio Amplifi er
■
When using optical fi ber cable:
It is possible to output audio through the DIGITAL AUDIO OUTPUT terminal. (See page 32 for details.) PCM audio
outputs from the terminal.
DIGITAL AUDIO INPUT
OPTICAL
Rear of the TV
Optical fi ber cable
• Depending on the connected equipment, audio will not output from the DIGITAL AUDIO OUTPUT terminal in HDMI
connection. In this case, set the audio formats of the connected equipment to PCM, 32/44.1/48 kHz.
■
When using audio cable:
ANALOG AUDIO IN
Rear of the TV
AUDIO-R (Red)
AUDIO-L (White)
Audio cable
• See page 30 for details on the Output Select function.
