Main Sub
Item Content
Adjustment
code code range
27 Sets PPC
communication
parameters.
SIMULATION NO.27-
1.PPC COMMUNICATION TROUBLE SETTING
2.PC/MODEM TELEPHONE NUMBER SETTING
3.PC/MODEM ID NUMBER SETTING
4.PPC SERVICE START/END SETTING
5.PPC TAG NUMBER SETTING
INPUT SUB NO. AND PRESS PRINT SWITCH
27 01 Sets PPC
communication
trouble.
0-1SIMULATION NO.27- 1
PPC COMMUNICATION TROUBLE (U7-00)
SETTING[X]:_
0. TROUBLE DISPLAY OFF
1. TROUBLE DISPLAY ON
INPUT SETUP VALUE AND PRESS PRINT SW
[Content] Communication troubles (U7-00) between the PPC and PC/Modem in the PPC
communication system can be set.
If set for “0”, the copier will be hung up if any communication trouble occur.
If set for “1”, the copier will not be hung up if any communication trouble occur.
The current setting is displayed and a new setting can be entered.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated and the sub code
input screen is displayed. If the entered value is not valid, the input field is
cleared and the error buzzer sounds. If any value is not entered, the setting
remains unchanged and the sub code input screen is displayed.
[0-1]: Enters new settings
[C]: Clears the input field.
[PAUSE]: No setting is made and the sub code input screen is displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 51
