Main Sub
Item Content
Adjustment
code code range
30 Displays the
operating status
of the
paper/cassette
sensors.
SIMULATION NO.30- _
1.MONITORING MAIN UNIT PAPER SENSOR
2.MONITORING PAPER CASSETTE SIZE
INPUT SUB NO. AND PRESS PRINT SWITCH
01 Displays the
operating status
of the copier
sensors.
SIMULATION NO.30- 1
MONITORING MAIN UNIT PAPER SENSOR
PFD , PPD1 , PPD2 , PSD , POD
MPED , LPED , LLUD
TFD , CSWF , CSWL , CSWR
[PAUSE]KEY:END DISPLAY
[Content] The operating status of the copier sensors
Display Name Normal display/Highlighted
PFD Paper feed detector Paper absence/Paper presence
PPD1 Paper transport detector 1 Paper absence/Paper presence
PPD2 Paper transport detector 2 Paper absence/Paper presence
PSD Paper separation detector Paper absence/Paper presence
POD Paper exit detector Paper absence/Paper presence
MPED Manual feed non-paper detector Paper presence/Paper absence
LPED Lower cassette paper absence detector Paper presence/Paper absence
LLUD Lower cassette lift-up detector Down/Up
TFD Waste toner full detector OK/Full
CSWF Front cabinet open detector Closed/Open
CSWL Left-side cabinet open detector Closed/Open
CSWR Right-side cabinet open detector Closed/Open
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the sub code input screen is
displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
02 Displays the
operating status
of paper size
detection switch.
SIMULATION NO.30- 2
MONITORING PAPER CASSETTE SIZE
PWS1 , PWS2 , PWS3 , PWS4
PLS1 , PLS2
LCSS1 , LCSS2 , LCSS3 , LCSS4
[PAUSE]KEY:END DISPLAY
[Content] Displays the status of the manual feed tray paper width detection switch and the
paper length detection switch and each cassette size switch.
• Manual feed tray paper width detection switch
[AB series] [Inch series]
PWS1: A3 8
1
⁄
2
" × 11"
PWS2: B4 —
PWS3: A4R 5
1
⁄
2
" × 8
1
⁄
2
"
PWS4: B5R —
• Manual feed tray paper length detection switch
[Inch series]
PLS1: 8
1
⁄
2
" × 11"R
PLS2: 8
1
⁄
2
" × 11" R, 11" × 17", 8
1
⁄
2
" × 14"
9 – 56
