Main Sub
Item Content
Adjustment
code code range
41 02 Adjusts the
document size
detection
sensor.
[Content] The detection level of the document size detection sensor is adjusted.If the
[PRINT] key is pressed with the document cover open and without placing any
document, the output level of the sensor that has detected no document is read.
Then, if the [PRINT] key is pressed with the document cover open and a sheet of
A3 size paper placed on the document table, the output level of the sensor that
has detected a document is read. The judgement level is calculated by comparing
the above two output levels. Finally, the data status of the document size detection
sensor is displayed according to the judgement level stored in memory.
(a) Operation/display
The display is in: Reverse video when the document size detection sensor indicates
that the document is present
Normal state when the document size detection sensor indicates that
the document is absent.
The display is in: Reverse video when the CSW is open.
Normal state when the CSW is closed.
[PAUSE]: The execution of the simulation is stopped and the screen changes to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
03 Displays the
output value
and setting of
the document
size detection
sensor.
SIMULATION NO.41- 3
ORIGINAL SIZE PHOTOSENSOR SETUP
RCV LV SETUP
-- --- ---
B5 XXX XXX
A4 XXX XXX
B5R XXX XXX
A4R XXX XXX
B4 XXX XXX
A3 XXX XXX
[PAUSE]KEY:END DISPLAY
• <Inch format>
SIMULATION NO.41- 3
ORIGINAL SIZE PHOTOSENSOR SETUP
RCV LV SETUP
5 1/2 x 8 1/2 XXX XXX
11 1/2 x 8 1/2 XXX XXX
-- --- ---
11 1/2 x 8 1/2 R XXX XXX
-- --- ---
11 1/2 x 14 XXX XXX
11 1/2 x 17 XXX XXX
[Content] The output value and judgement value of the document size detection sensor are
displayed (0 ∼ 255)
(a) Operation/display
The level of the document size detection sensor is displayed.
[PAUSE]: The execution of the simulation is stopped and the screen changes to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 59
