Main Sub
Item Content
Adjustment
code code range
52 01 Sets ADU
alignment plate
adjustment
value.
1-99Adjustment range
ADU alignment plate adjustment value : 1 ∼ 99
The alignment plate spacing narrows about 0.56 mm for every “+1” in
adjustment value.
The alignment plate spacing widens about 0.56 mm for every “–1” in adjustment value.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated and the sub code
input screen is displayed. If the entered value is not valid, the input field is
cleared and the error buzzer sounds.
If any value is not entered, no setting is made and the screen changes to
the sub code input screen.
[0-9]: Enters new settings.
[C]: Clears the input field.
[PAUSE]: No setting is made and the sub code input screen is displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
02 Sets ADU
trailing edge
adjustment
value.
0-99SIMULATION No.52- 2
ADU REAR PLATE ADJUST VALUE SETUP
ADJUST VALUE[XX]:_
(0~99)
INPUT SETUP VALUE AND PRESS PRINT SW
[Content] The adjustment value of the ADU trailing edge plate stopping position can be set.
The current setting is displayed and a new setting can be entered.
Adjustment range
ADU trailing edge plate adjustment value: 0 ∼ 99
The trailing edge plate spacing decreases 0.4 mm for every “+1” in adjustment value.
The trailing edge plate spacing increases 0.4 mm for every “–1” in adjustment value.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated and the sub code
input screen is displayed. If the entered value is not valid, the input field is
cleared and the error buzzer sounds.
If any value is not entered, no setting is made and the screen changes to
the sub code input screen.
[0-9]: Enters new settings.
[C]: Clears the input field.
[PAUSE]: No setting is made and the sub code input screen is displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
03 Sets ADU drive
clutch OFF time.
0-10SIMULATION No.52- 3
ADU DRIVE CLUTCH OFF TIME SETUP
OFF TIME SETUP[XX]:_
(0~10)
INPUT SETUP VALUE AND PRESS PRINT SW
[Content] The Adjustment value of the ADU drive clutch OFF time can be set. The current
setting is displayed and a new setting can be entered.
