Main Sub

Item Content

Adjustment

code code range

53 06 Adjusts RADF

repulsion

sensor.

0-127SIMULATION No.53- 6

RADF REPULSION SENSOR ADJUSTMENT

PRINT SWITCH:EXECUTE SIMULATION

• Eject/inversion sensor adjustment completed

SIMULATION No.53- 6

RADF REPULSION SENSOR ADJUSTMENT HAS

COMPLETED

ADJUSTMENT VALUE:XXX

[PAUSE]KEY:END DISPLAY

[Content] The RADF repulsion sensor can be adjusted.

If the [PRINT] key is pressed to execute the simulation, the RADF repulsion

sensor reference value is adjusted and the adjusted value is displayed.

Adjustment range

RADF: 0 ∼ 127

(a) Operation/display

[PRINT]: The adjustment simulation is executed.

[PAUSE]: The execution of the simulation is stopped and the sub code input screen is

displayed.

[CA]: The execution of the simulation is stopped and the simulation is terminated.

07 Adjusts RADF

timing sensor.

0-127SIMULATION No.53- 7

RADF TIMING SENSOR ADJUSTMENT

PRINT SWITCH:EXECUTE SIMULATION

• Timing sensor adjustment completed

SIMULATION No.53- 7

TIMING SENSOR ADJUSTMENT HAS COMPLETED

ADJUSTMENT VALUE:XXX

[PAUSE]KEY:END DISPLAY

[Content] The RADF timing sensor can be adjusted.

If the [PRINT] key is pressed to execute the simulation, the RADF timing sensor

reference value is adjusted and the adjusted value is displayed.
