B. Desk unit
a. Cut the PP band.
b. Open the exterior box.
c. Remove the packaged items:
1) Remove the short spacer package assembly
2) Remove the screw package assembly A.
3) Remove the screw package assembly B.
4) Remove the instruction manual.
d. Remove the upper pad.
e. Remove the vinyl sheet.
f. Remove the desk unit.
Screw package assembly B
Taped to recession in the
upper pad
Screw package assembly A
Taped to recession in the
upper pad
Lower pad
Bottom case
Exterior box
Instruction Manual
Short spacer package assembly
Taped to recession in upper pad
Upper pad
Copier vinyl sheet
Desk unit
5 – 3
