Sharp AR-5132

2 Paper feed motor peripheral
3 Paper feed section (Front side)
4 Reverse unit section (Front side)
5 Reverse unit section (Rear side)
6 Tray inside
Document
sensor (DSS)
Paper feed motor
(DFM)
Paper feed motor rotation
sensor (DRMRS)
Paper feed motor
rotation sensor
SENSOR 2 harness
Paper feed motor (DFM)
Paper feed
guide switch
(FGOD)
Drive F harness
TR2 harness
SENSOR harness
SENSOR 2
harness
Paper feed solenoid (DFSOL)
SOL harness
RU harness
Reverse solenoid (DRSOL)
Control PWB
RU harness
Reverse motor (DRM)
Drive R harness
Reverse guide switch
(TGD)
Document length sensor 2 (DLS2)
Documentl length sensor 1 (DLS1)
Document end
sensor (DED)
Document width volume
sensor (DWVR)
Tray harness
(Inch series only)
7 – 20
