Sharp AR-6020DV

AR-6020V SPECIFICATIONS 2 – 1
AR-6020V
Service Manual
[2] SPECIFICATIONS
1.Basic specifications
A.Engine Composition
B.Engine speed (ppm)
(1)Tray 1, 2
(2) Bypass tray
C.Printable area
* When making original size/one-sided copies, the first sheet from
the bypass tray has no back end void setting.
D.First Copy Time
First copy time from the paper feeding unit
E.Engine resolution
F. Scanner section
(1)Resolution/Gradation
(2)Document table
Photoconductor OPC Drum (φ30mm)
Recording method Electronic Photo (Laser)
Developing method
Dry-type Dual component Magnetic Brush
Development
Charging method Charged Saw-Tooth Method
Transfer method Transfer roller
Separation method Separation claw
Cleaning method Contact blade method
Fusing method Heat roller
Toner supply method Open the front cover and insert the cartridge
Toner supply while working Unavailable
Appearance Pastel white
Paper size (short
edge feed)
20cpm 23cpm 26cpm 31cpm
A4/ 8.5"x11" 20ppm 23ppm 26ppm 31ppm
A4R 14ppm 15ppm 18ppm 23ppm
8.5"x11"R 15ppm 16ppm 18ppm 23ppm
A5/ 5.5"x8.5"R 20ppm 23ppm 26ppm 31ppm
B5/ 16K 20ppm 23ppm 26ppm 31ppm
B5R 16ppm 18ppm 18ppm 23ppm
16KR 15ppm 16ppm 18ppm 23ppm
8.5x13" 12ppm 13ppm 16ppm 20ppm
B4/ 8.5"x14 12ppm 13ppm 16ppm 20ppm
A3 11ppm 12ppm 15ppm 17ppm
11"x17" 10ppm 11ppm 15ppm 17ppm
8K 11ppm 12ppm 15ppm 17ppm
Paper size (short
edge feed)
20cpm 23cpm 26cpm 31cpm
A4 16ppm 18ppm 24ppm 29ppm
8.5"x11" 16ppm 18ppm 24ppm 29ppm
A4R/ 8.5"x11"R 10ppm 11ppm 19ppm 25ppm
A5 16ppm 18ppm 25ppm 29ppm
5.5"x8.5" 16ppm 18ppm 25ppm 29ppm
A5R/ 5.5"x8.5"R 16cpm 18cpm 25ppm 29ppm
B5 16cpm 18cpm 24ppm 29ppm
16K 16cpm 18cpm 24ppm 29ppm
B5R/ 16KR 10ppm 11ppm 19ppm 25ppm
8.5x13" 10ppm 11ppm 16ppm 21ppm
B4 10ppm 11ppm 16ppm 21ppm
8.5"x14 10ppm 11ppm 16ppm 20ppm
A3 10ppm 11ppm 15ppm 18ppm
11"x17" 10ppm 11ppm 15ppm 18ppm
8K 10ppm 11ppm 15ppm 17ppm
A3 293x413mm
B4 253x357mm
A4 206x290mm
B5 178x250mm
A5 144x203mm
A5R 203x144mm
8K 266x383mm
16K 191x263mm
11x17 275x425mm
8.5x14 212x349mm
8.5x13.5 212x336mm
8.5x13.4 212x333mm
8.5x13 212x323mm
8.5x11 212x272mm
5.5x8.5 136x209mm
5.5x8.5R 209x136mm
Executive 180x260mm
Void area
Front end: 1 to 4mm, Back end: 1 to 5mm, Both sides:
Max. 6mm
Image loss
Front end: 4mm or less, Back end: 1 to 5mm, Right/Left :
Total 6mm or less
Loss width
Front end/Back end: 4mm or less , Right/Left : Total
6mm or less
20cpm 23cpm 26cpm 31cpm
Platen
A4: 6.4
seconds
LT: 6.5
seconds
A4: 6.4
seconds
LT: 6.5
seconds
5.2seconds 5.2 seconds
20cpm 23cpm 26cpm 31cpm
Platen 12.5 seconds 12.5 seconds 10.9 seconds 10.9 seconds
Resolution
Copy
<Writing>
600 x 600dpi
Print
<Writing>
600 x 600dpi
Tone
Copy
<Writing>
600 x 600dpi x 1bit
Print
<Writing>
SPLC : 600 x 600dpi x 1bit
PCL : 600 x 600dpi x 1bit
PS : 600 x 600dpi x 1bit
Scan Resolution for
Copying (dpi)
Monochrome
Document Glass 400x600dpi
RSPF 400x600dpi
Transmission Resolu-
tion (dpi)
Refer to Image Send Function.
Exposure Lamp White LED
Scan Levels 256 levels
Output Levels
Monochrome : 1bit
Gray scale : 8bit
Full Color : RGB each color 8bit
Form Fixed original glass (Flatbed)
Scan Range 297x431mm
Standard Location of Original Rear Left
Original size detection No
Heater (scanner section) No
A3 293x413mm
B4 253x357mm
A4 206x290mm
